OPERATION PIPE

Assembly drawing

Please use your mouse to zoom in and out for more detailed view

OPERATION PIPE

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref No Description Price
033 6684838 BOLT £2.27 Add
034 6684831 BUSH ASSY £4.21 Add
035 6684832 DRIVE SHAFT B £15.49 Add
036 6684833 BUSH £4.06 Add
